Pallet transport system – insertion module – Its task is to quickly and easily transport pallets and guide pallets onto transfer modules. The device consists of a steel housing, chain guides, bumpers, shaft and drive.
.webp)
Product specifications:
Maximum load: 1200 kg
Ambient temperature: 0°C ÷ 40°C
Chain: 10B2
Drive elements: Chain
Maximum speed : 0.3 m/s
Voltage type: 400V
Approach angle: 4° ÷ 6.5°
Technical specifications:
B / Width / 760 mm
L / Conveyor length / 2094 mm
H / Height / 224 ÷ 309 mm
